Overview
Product Attributes

Model No.ELS600VDC52800W

BrandAPM

Place Of OriginChina

Input Voltage0~600V

Input Current0~3000A

Input Power0~52800W

Voltage Readback Accuracy0.015%+0.015%F.S.

Current Readback Accuracy0.04%+0.04%F.S.

Power Readback Accuracy0.1%+0.1%F.S.

Height36U

Measurement Frequency500kHZ

CCD/CRD Precision5%±10us

Supply Ability & Additional Information

PackagingWooden Case

Productivityother

TransportationOcean,Land,Air

Place of OriginCHINA

Supply Abilityother

CertificateISO9001/CE/ROHS/CSA/UL

HS Code8543709990

PortDHL

Payment TypeT/T

IncotermEXW

Packaging & Delivery
Selling Units:
Piece/Pieces
Package Type:
Wooden Case
Picture Example:

APM techonogies high power programmable dc electronic load system 600V 52800W allows automatically switches among CV, CR, CC and CP modes. It is suitable for lithium ion battery charger testing to get a complete V-I charging curve. This flexible auto mode also enormously improve test efficiency.
APM techonogies also have DC Electronic Load System with 200V DC Electronic Load System,1200V DC Electronic Load System for exta voltage options.
This series DC electronic load can be applied to battery discharge, DC charging station and power electronics and other electronics products.

Features:

● Provides four kinds of basic working mode such as CV/CC/CR/CP, and CV+CC/CV+CR/CR+CC complex operating modes.
● Adjustable current slew rate, CV loop speed DC electronic load.
● Ultra high precision voltage & current measurement.
● Short circuit test mode.
● Auto mode function provides an easy way to do complicated test.
● V-monitor/I-monitor.
● Full protection: OCP, OPP, OTP, over voltage and reverse alarm.
● Equipped with Emergency Stop, physically off all managed DC eLoads at once.
● Back door with protect switch, safe to the operator.
● Front panel USB interface supports data import and export.
● Using standard SCPI communication protocol.
